In many locations throughout all Synthesis desktop applications, you can use flexible filters to limit a list of projects, project items (e.g., folios, diagrams, system hierarchy items, etc.) or resources (e.g., models, URDs, etc.).
Use the drop-down list to apply or remove an existing filter:
Show All (formerly called “Default filter”) means that a filter is not currently applied.
The list also contains the filters you have saved in this database, plus any filters that another user has saved and marked Show to all repository users.
To create a new filter, click Add Filter (
).
To edit an existing filter, select it from the list and click Edit Filter (
).
To permanently delete a filter from the database, select it from the list and click Delete Filter (
). (If you simply wish to stop filtering the list, select Show All instead.)
Now in Version 10, any user can choose to share a saved filter with all other database users. To share a filter, open its properties window and select the Show to all repository users check box.
In a secure database, a shared filter can be edited or deleted only by a) the user who created the filter or b) a user with the “Manage other repository settings” permission.
